Sunday, July 7, 2013

Mondo Cane

The P-38
Baron Samedi knows, all things dead grow.
     Here's a new morph (not so new- it's been ridden, and ridden well) of the P-38.
Working off the Old Guy, as well as the Tombstone and the Archer,
this guy has a lot more of the now-classic mini-Simmons feel off of the tail, with the same full-rail feel on front-foot turns as the original P-38.
True to my "front foot, hull, back foot, fins" turn philosophy, this morph has a fuller, tucked under edge in the back rail, while maintaining a follow-through forward, in both rail and bottom,
into a true hull front end. A big change is the nose template; I switched to the Lurker nose; this provides a more concentrated corner for front-rail turns, as well as losing 1" of front nose for a better turn hinge and better duck-diving.
The template: a double ender: this one is 5'8, Mondo Cane is 5'6. Both are 18 1/2 x 22 x 18 1/2", 3" thick. A Classic 1982 Pool Skateboard template.
The bottom is the sure-fire, front hull to panel vee in between the fins, to a flat exit ( in this case, as usual, immediately behind the fins, to firm the tail and add rooster-tail spray value). The fins differ from your typical Mini-Simmons; in my opinion, the fins are the engines with twin fins, so this is a fin with a lot of drive with a pivot potential. With drive in mind, they are not two sided foils. Actually, Marlin Bacon at 101 Fins talked me into a wonderful fin- a 60% outside/ 40% inside front foil, flowing to a 90% outside/10% inside... Front for steer, rear for drive, not to mention the flex properties of  bamboo fins, when properly foiled.  The template is also a slap in Mini-Simmons' faces- it's a tweak off the classic Steve Brom fish fin; narrower at base, higher in aspect, it pivot-turns with drive when you expect to endure a
momentum-robbing slide.
     These two guys are for sale in Val Surf in NoHo.

Friday, June 28, 2013

Ant times two

Yeah, Tim. Yeah, Aaron (the original- the namesake- Aaron's New Toy- A.N.T.).
     I'm back on an Ant; but this time, times two:
     This ANT is just an as-usual Ant; 9'3, 22 1/4 (wide for me!), a taste under 3" thick. Typical.
The other Ant is, actually, a MicroAnt- the MicroAnt as it should have been, but for which the world was not yet prepared when I shaped the first MicroAnt. Think about a Hot Generation with less nose width, the same tail-friendly hull-to-vee bottom, with more curves and corners to turn off of:
This board is a 7'3 morph of a board I've been playing with for over a year now- Called, initially,
the EV: I'm thinking of it as the MA III, or the MA-EV, or the EV, for short. It carries the mass distribution and bottom contour of the Hot Generation, as well as some of the pertinent template, but, as said before, it has more curves to turn off of.
I'm anticipating duck-dive-ability with the narrower nose:
This board is weighing in at:
7'3; 16 3/4 x 21 5/8 x 16 1/8, 1.5" nose, 3.15", 3" back, 1.9" tail in thickness. The template is prettier with  a wider wide-point, but I'm conscious of my foot size, and I didn't want to push wider, personally, past 21 3/4".
     There isn't a board made under 8' that I can't duck-dive with this nose. I came really close to duck-diving
my 8'0 Hot Generation!
     But, as Darth Vader always says: "We'll see!".
This board has had great reviews in Hot Gen sizes for over a year- i.e., between 8'0 and 8'6. A lot like the PHd Puerto Rico, but it is stronger off the tail in an aggressive turn. Like the HotGen- the harder you push it, the stronger it will reward you. I'm seeing that this template will go to original MicroAnt sizes, 7'0 to 7'6, sizes that the Hot Gen won't easily go. I'm excited.
     The Ant:
9'3. Sooo Tim Elsner, that I blush, but I've been 8 years without an Ant ( I've been riding an Avenger, but the last two seasons of "longboard" go-outs have been on an 8'0 Hot Generation- it doesn't count).
Just an average, dime-store Ant, but it's mine!

Thursday, June 27, 2013

3-Dimensional Shaping

Something I Noticed This Week

      A typical Waterman's week, in summer. Making my garage's sides bulge with shaped blanks, while I'm praying The Big One (earthquake) will wait a day. Daylight didn't reveal this other three-dimensional shaper, but happily (or, unhappily, for me- I was still working), I caught this set of 3-D curves right at the doorway last night.
The pic doesn't do it justice. Too much is going on. Neither Leibnitz nor Newton invented calculus (or, as Newton called it, rather poetically, Fluxions). Little Spidey Man knows it in his exoskeleton; has known it for a helluva longer than I have, even if I had to learn it... maybe from him?


Monday, April 22, 2013

New Hully Short Stuff

Here's a couple of new short guys that I've been working on for close to a year.
The Egg On Acid. A hyper short version of the Tri-Egg, it carries the classic soft egg rail on top of the hull,
with a kink in the template and tail rocker, along with a barreled V to give a solid pivot off of the tail.

This one is 5'11, 17" x 21 1/4" x 16 1/2". I've made them anywhere from 5'7 to 6'2, and it probably
can go a little bigger, as well.
       The other board is the VeeBee:
Obviously, a variant of the GeeBee. This one is 5'9, 18 1/8 x 21 x 17. The difference is in the tail: it stays wider in the back third, and corners into a narrower tail block, more like Velo, hence the name. Bottom-wise, it also goes into a firm Vee in the tail, with a rocker kink.

Otherwise, this board has the same rocker, bottom, and committed hull rail as the GeeBee.
On both these boards, I've opened up the fin options. Both can be ridden as single fins (of course),
but by using standard 2-plug FCS for the side boxes, two different fin setups can go down.
One would be the classic GeeBee/MP one-plus two setup:
This setup is the classic for more committed rail turns. A more tail-friendly option is this:
A two-plus one setup. Either way, both of these boards have a different feel. I dig 'em!



Monday, May 21, 2012

9'4'' SOS, PHD

Flo's 9'4'' SOS



Brian set this blank up nice with the stringers coming right out at the corners.











Nice, Watermans Guild volan glass job.



Upon the front 3rd on this and it will take off with out you if your not ready.







This one came out nice .



Thursday, July 28, 2011

RHAnt

I really like Tim: he knows what he wants, has an idea of what it should look like, but is wise enough to throw a clue as to the board's ultimate purpose.
This could be anywhere in Cali, during any era. It's what I heard Tim saying he wanted.
So I shaped him this:


Just an ANT. Never "just" for anyone who Knows What They Want- but an Ant, nonetheless. But after a few rides, more info bubbles up from Tim, about something we no longer have, both in surf, and in rider- Russell Hughes, dead last May. I begin to understand: He saw this,

And he was thinking this: Russ on the left.


I'm just happy he could ride like this. Sounds like he is, too.

Wednesday, July 13, 2011

Where Next?


Where next? After Vancouver,maybe right here. The strongest-yet southern hemi popped in right about the same time I got back in town ( I wish it showed up a week early!). While I've had no time to partake (paying off for Travel Fun), I'm sure some local feedback will arrive. I'm planning on sloppy seconds at the end of the week (before Carmageddon).
Whatever, it's L.A.

Thursday, June 23, 2011

The Great Green North










TeePee surf camp




Moonshine








Storm Jonny

Sunday, June 19, 2011

9'0'' and 8'0''

8'0'' Hot Generation




9'0'' Combo of L-spoon , HG and Fineline Microant, these 2 are Mr. Elsners. Good feedback on both of these.



Wednesday, June 15, 2011

Monday, June 13, 2011

Saturday, June 11, 2011

Surf Craft. Ho Ho, 'Ho

'Tis the season. Ho, Ho, you 'Ho. Lot's o' sleds.
surf craft

Friday, June 10, 2011

Hull at Chasm
Hull at Beach
Hull at Home


Hull not wanting to be home


Hull in Butt
